Applying the technology to the manufacturing process of the product turns out to be highly helpful. Featuring stability and durability, the product is suitable for the field(s) of Liquid detergent mixer. The accumulated rich experience and strong technological innovation capabilities have kept Guangzhou Guanyu Machinery Co.,Ltd at the forefront of the market, and Hand Soap Gel Production Plant Detergent Blending Tank Toilet Cleaner Agitator Chemical High Shear Mixer Homogenizer Machine developed have perfectly solved the pain points of the industry and the market. The specifications of Hand Soap Gel Production Plant Detergent Blending Tank Toilet Cleaner Agitator Chemical High Shear Mixer Homogenizer Machine can be customized according to your needs.
Mixer Type: | Homogenizer | Barrel Volume (L): | 500 |
Material Processed: | Plastics, Chemicals, Food, Medicine | Max. Loading Volume (L): | 500 L |
Range of Spindle Speed(r.p.m): | 1 – 63 r.p.m | Max. Loading Capacity: | 5-5000L |
Weight (KG): | 260 KG | Material: | SUS304, SUS304L, SUS316, SUS316L, Stainless Steel 316 and SS304 |
Condition: | New | Product Type: | butter |
Application: | Liquid, Medicine/Plastics/Chemicals /Food Processing | Additional Capabilities: | Blending/Dispersing /Heating/Cooling |
Place of Origin: | Guangdong, China | Brand Name: | GuanYu Chemical Mixing Equipment |
Voltage: | 220V/380V 50HZ | Dimension(L*W*H): | Custom Made |
Power (kW): | 15 kW | Warranty: | 1 Year |
Key Selling Points: | Competitive Price | Applicable Industries: | Hotels, Manufacturing Plant, Farms, Restaurant, Home Use, Retail, Printing Shops, Food & Beverage Shops |
Showroom Location: | Egypt, Italy, Peru, Mexico, South Korea, Algeria, Kazakhstan, Ukraine, Tajikistan | Marketing Type: | New Product 2020 |
Machinery Test Report: | Provided | Video outgoing-inspection: | Provided |
Warranty of core components: | 1 Year | Core Components: | Motor, Gear, Pressure vessel, Gearbox, Pump, PLC |
After-sales Service Provided: | Engineers available to service machinery overseas | Motor Brand: | ABB or Siemens |
Surface treatment: | Polish | Blending Rotation: | 0~65 R/min |
Homogenizing Rotation Speed: | 3000 R/min | Motor: | Mixing Motor/Reducer/Homogenizer/Thermometer |
Optional components 1: | Electrical Hot Rod/Steamer Generator/Frquency Convertor | Optional components 2: | Suction Feeding Pump/Storage Tank |
Model | Volume(L) | Blending power(kw) | Blending rotation speed(r/min) | Homogenizing power(kw) | Homogenizing rotation speed(r/min) | Heating method | |
GYM-200 | 200 | 1.5 | 0~63 | 4.0 | 0~3200 | Steam heating Or Electric heating | |
GYM-500 | 500 | 3.0 | 0~63 | 7.5 | 0~3200 | ||
GYM-1000 | 1000 | 4.0 | 0~63 | 11 | 0~3200 | ||
GYM-1500 | 1500 | 5.5 | 0~63 | 11-15 | 0~3200 | ||
GYM-2000 | 2000 | 7.5 | 0~63 | 15-18.5 | 0~3200 | ||
GYM-3000 | 3000 | 7.5-11 | 0~63 | 18.5-22 | 0~3200 | ||
GYM-5000 | 5000 | 11-15 | 0~63 | 18.5-22 | 0~3200 |
◭The all-round wall scraping mixing adopts the frequency converter for speed adjustment , so that high quality products ofdifferent processes according to customer requirements.
◭The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve manyindissoluble materials such as AES , AESA , LSA , etc. during the liquid detergent production p reactor stirred tankrocess so as to save energy consumpion and shorten production period.
◭The pot body is welded by imported three-layer stainless steel plate. The tank body and the pipes adopt mittor polishing , which fully conforms to GMP requirements. reactor stirred tank
◭According to customer requirement , the tank can heat and cool materials. The heating way including steam heating and electric heating. Easy to discharge , bottom direct discharge or by transfer pump. reactor stirred tank
