sealing machine for food Guanyu High Quality Pump Cap Medicine Automatic Plastic Bottle Jar Capping Machines For Pet Bottles Screw Capping Machin

This machine is used for automatic capping of plastic bottles and glass bottles in cosmetics,food and beverage,pesticide and fertilizer,chemical industry.



Adjustable capping torque control greatly reduces the wear of capping wheel and ensures the quality and precision of capping



Edit Content

sealing machine for food Guanyu High Quality Pump Cap Medicine Automatic Plastic Bottle Jar Capping Machines For Pet Bottles Screw Capping Machin

Product Parameters





Bottle height30-300mmCap Diameter18-70mm
Bottle Diameter20-160mmWorking speed20-60 bottles/minute

(depending on bottle and cap size and shape)

Working voltageAC220V/110V 50-60HZWorking pressure0.4-0.6 MPa
Size Of air compressor connectorOD 8mmDimensionAbout 1930*740*1600mm
Packing sizeAbout 2000*820*1760mmNet weight/Gross weightAbout 113kg/192.5kg



Product Details



sealing machine for food

Control Panel

Intelligent operation panel and is with English version,can control working time and set working mode.

sealing machine for food

Emergency Stop Button

With Stop button,can protect the machine from damage and keep the operator safe during working.

sealing machine for food

Conveyor

The conveyor width can be adjusted according to the bottle diameter.The transferring speed is adjustable by operation panel.







sealing machine for food

Height adjustment

The working height is adjustable according to the bottle height by otating this knob.This makes sure this machine can be used for as many as ossible caps.



sealing machine for food

Capping Chuck

Suitable for different kinds of bottle caps.The capping time,pressing time can be adjusted by operation panel.

sealing machine for food

Adjustment

The electric eye is used to detect the bottle, and the production is fully automated. The sensitivity of the electric eye can be adjusted according to the production needs to improve the accuracy of capping.

Scope of application

sealing machine for food
